Cameo P6

High output | Energy efficient LED | Full spectrum ellipsoidal spot | RGBACL colour mixing | High CRI (>97 Ra ) & TLCI (>91) | 18,000 lm | Four-blade framing | Integrated zoom (5°-50°) | Infinitely variable integrated frost filter

The Cameo P6 LED profile spotlight offers a powerful 600 W RGBACL engine and 18,000 lumens – an ideal energy-efficient replacement for traditional 2.5 kW halogen profile lights in theatres and live performance venues.

This modern theatre lighting fixture combines excellent lighting quality and natural colour reproduction with flexible lighting design tools – impressive in theatres, TV studios, conference & live performance event stages.

The Cameo P6 boasts XColour™ technology designed & engineered in Germany, for an extremely precise colour calibration mixing system based on the RGBACL (RGB + Amber + Cyan + Lime) LED engine.

Additionally, the high CRI of over 97 Ra and a TLCI value of over 91 ensure vibrant presentation of people and objects with clear and dynamic colours. For white light, the colour temperature can be continuously adjusted between 2,700 K and 6,500 K.

This powerful LED profile spot easily adapts to different stage requirements with an integrated zoom in the 5° to 50° range whilst the 360° rotatable four-blade framing system and infinitely variable integrated frost filter (the iris and gobo holders supplied can be optionally added via a slot system) facilitate a wide array of creative light-shaping options.

An LED service life of around 50,000 hours and 70% saving on power consumpition compared to old 2.5 kW halogen profile lights make the P6 a future-proof lighting solution. In addition to the overarching “Green Deal” (aiming for climate neutrality by 2050), the harmonisation of ecodesign guidelines for light sources within the European Union also plays a role here.

The P6 meets the high demands of everyday use for lighting technicians, directors, and other professionals for virtually silent operation in every position.

  • Future-proof LED Profile Spotlight meeting coming EU regulations
  • 18,000 lm luminous flux replaces conventional 2.5 kW halogen profile lights
  • 600 W RGBACL LED (RGB, Amber, Cyan, Lime)
  • High CRI (>97 Ra ) and TLCI (>91) for natural colour rendering
  • Seamless colour temperature adjustment from 2,700 K to 6,500 K
  • Extremely precise, calibrated XColour™ colour mixing
  • Manually operated zoom range (5° - 50°) and additional focus
  • Protected and registered stepless, linear frost for versatile and seamless beam shaping
  • 360° rotatable four-blade framing system
  • Dual slot-in system for flexible combination of iris and gobo holder, with manual rotation
  • 70% lower power consumption compared to conventional
  • 2.5 kW halogen profile lights
  • Whisper-quiet operation
  • Cameo Item number CLP6
  • Warranty: 2 Years
z:Artnet z:COB z:Focus z:sACN z:4-shutter z:iris z: RGBALC
List Ex VAT: Contact Us
Log in for Trade Prices
CONTACT US

SPECIFICATIONS

Illuminant type

LED RGBALC

Illuminant power

600 W

Luminous flux

18,000 lm

Exchangeable lens

Yes

Zoom range

5 - 50 °

Focusing type

Manual

LED PWM frequency

1,530 Hz, 3,600 Hz, 12 kHz, 18.9 kHz, 25 kHz

Dimmer resolution

16 Bit

Dimmer curves

Linear, Exponential, Logarithmic, S curve

LED colours

Red, Green, Blue, Amber, Lime, Cyan

Correlated colour temperature (CCT)

2,700 - 6,500 K

Halogen simulation redshift/DTW

Yes

Calibration

Smart calibration

Colour rendering index (CRI)

> 97

Iris

Yes

Framing blades

Yes

Module rotation

0 - 360 °

Controller protocols

Art‑Net, DMX512, RDM, sACN, W‑DMX™ (Transceiver)

Number of DMX control modes

16

Operation voltage

100 V AC - 240 V AC / 50 - 60 Hz

Rated power

700 W

Housing

Metal, Black

Cooling system

Temperature controlled fan cooling

Cooling modes

Auto, Max. intensity, Silent, On/Off

Dimensions W x H x D

730mm x 579mm x 410mm

Weight

23 kg
