Waves System NanoPlayer Box+

The Waves System (iD-AL) NanoPlayer Box+ (50058) plays WAV/MP3 audio files stored on an SD card.

The incredibly compact Nanoplayer Box+ also features an integral 2 x 8 watt amplifier enabling standalone operation via two headsets or two passive speakers.

Audio content automatically plays upon powering up the player with autoplay mode or can operate interactively via an input contact such as a push button, motion sensor etc or optional infrared remote control.

Audio files are organised simply with a file manager. The naming and the structure of the audio files define their playback.

Ideal for broadcasting messages, sound effects or music through a public address background music system.

45 watt power supply included.
  • Warranty: 3 Years
SD
List Ex VAT: £235.45
Log in for Trade Prices
CONTACT US

SPECIFICATIONS

Interfacing and Connectors:



Headphones

2x stereo 3.5mm mini-jack: 250mW - 8 Ohms - THD 1%

Line Out

Stereo 3.5mm mini-jack: unbalanced

Speaker Outputs

2 × 8 W – 8 Ω, THD+N = 1 %, 1 kHz

2 × 10 W – 8 Ω, THD+N = 10 %, 1 kHz

2 × 13 W – 4 Ω, THD+N = 1 %, 1 kHz

2 × 16 W – 4 Ω, THD+N = 10 %, 1 kHz

Digital Input

Opto-isolated terminal block connector 3.81mm

Power supply output

3.81 mm pluggable terminal block

Supported Audio Files

MP3 (.mp3): MPEG-1/2 Audio Layer III, mono/stereo, 16 bits, 44.1 kHz, from 32 kbit/s to 320 kbit/s, CBR (Constant Bit Rate) or VBR (Variable Bit Rate), with or without ID3v1/2 tags¹
WAV (.wav): mono/stereo, 16-bit LPCM, 44.1 kHz, WAVE_FORMAT_PCM or WAVE_FORMAT_EXTENSIBLE.

Storage Devices

File system supported: FAT32

Accepted storage device types:

SDSC cards, SDHC cards, SDXC cards

Accepts 2 folders maximum at the root, containing up to 999 files each

Player power supply input:

Nominal voltage: 12 V DC

Voltage

From 100 V to 240 V

Frequency

From 50 Hz to 60 Hz

General

AC 230 V, 50 Hz (UK/Europe)

Dimensions  (WHD)

75 mm x 25 mm x 125 mm

Weight

108g

DOWNLOADS

Waves System iD-AL NanoPlayer Datasheet
Waves System iD-AL NanoPlayer Manual
